Ariston Flues Data

Flues and accessories Ariston have an extensive array of flues and accessories which can be applied to suit most flueing installation methods. Ariston boilers are designed to be completely adaptable, whether you need to alter flue components or wish to add accessories for comprehensive installation options. Flue turrets Alteas ONE+ Net, Genus ONE+ WiFi, CLAS ONE, CLAS ONE R, CLAS SYSTEM ONE, E-COMBI ONE AND E-SYSTEM ONE Coaxial exhaust Twin pipe exhaust 200 200 120 120 180 120 180 105 105 195 Maximum flue lengths Our reference 15 18 24 30 35 38 Horizontal Coaxial 60/100 (mm) 13 8 8 7 6 6 Horizontal Coaxial 80/125 (mm) 30 32 33 24 24 27 Vertical Coaxial 60/100 (mm) 13 8 8 7 6 6 Vertical Coaxial 80/125 (mm) 30 32 33 24 24 27 Twin Pipe (equal lengths) 38/38 36/36 24/24 26/26 23/23 16/16 | 1
